Space saving – the smallest size is less than 1 meter square -
70% of the footprint is passenger space. -
Machine roomless and no pit needed -
Color: Black/ White -
Can work with single phase electricity
-
Can be installed in just 7-10 days -
A Cibes Uno platform lift with standard doors requires a headroom of only 2300 mm -
The EcoSilent drive system makes lift operation 45% more energy-efficient and is virtually soundless
-
Comply with European Safety Standard Machinery Directive 2006/42/EC and also the local standards More than 200 different lift colors for you to choose
-
Installation location: Indoor/Outdoor
-
Load capacity: 300kg/ (2-4 people) and 400 - 500kg/ (5-7 people)
-
Maximum number of stops: 6
-
Maximum speed (m/s): 0.15m/s
-
Travel height: 20m
-
Min headroom: 2300mm
-
Pit depth: 70mm - 0mm and install straight on the floor
-
Drive system: Screw and nut
-
Directives and standards: MD 2006/42/EC, EN 81-41
Popular Sizes
| Dimention | Platform size (mm) | Cut out size (mm) |
|---|---|---|
| 1 | 635x850 | 1070x940 |
| 2 | 935x1050 | 1370x1140 |
| 3 | 1035x1050 | 1470x1140 |
| 4 | 1135x1250 | 1570x1340 |
| 5 | 935x1450 | 1370x1540 |
DESIGN
Black
White
